Ensure reliable and efficient power delivery with GIGABYTE power supplies. Designed for peak performance and durability, our PSUs offer stable and consistent energy to power your high-performance systems. With advanced protections and high-quality components, GIGABYTE power supplies provide the confidence you need for seamless, uninterrupted computing experiences.
16-pin PCIe cable * 4 support PCIe Gen 5.0 graphic cards|ATX 3.1 and PCIe Gen 5.0 ready|Server-grade Ultra Durable: Main Japanese capacitors, enhanced thermal solution, 140mm smart double ball bearing fan, OVP/OPP/SCP/UVP/OCP/OTP protection|80 PLUS Platinum certified|Fully modular design|Powerful single +12V rail
- Fan diameter:
- 12 cm
- Fan location:
- Top
- On/off switch:
- Yes
- Cooling type:
- Active
- Peripheral (Molex) power connectors (4-pin):
- 6
- Weight:
- 5.3 kg
- Package width:
- 410 mm
- Package depth:
- 219 mm
- Package height:
- 145 mm
- Package weight:
- 5.58 kg
- Power supply unit (PSU) form factor:
- ATX
- 80 PLUS certification:
- 80 PLUS Platinum
- ATX version:
- 3.1
- Bearing technology:
- DBB
- Mean time between failures (MTBF):
- 100000 h
- Motherboard power connector:
- 20+4 pin ATX
- Motherboard power cable length:
- 61 cm
- Number of SATA power connectors:
- 16
- PCI Express power connectors (6+2 pin):
- 8
- CPU power connector (4+4 pin):
- Yes
- ATX power connector (20+4 pin):
- Yes
- PCI Express connector:
- Yes
- Cabling type:
- Fully-Modular
- SATA power cable length:
- 150,650 mm
- EPS power connector (4+4 pin):
- Yes
- AC input voltage:
- 100 - 240 V
- AC input frequency:
- 50/60 Hz
- Input current:
- 15 - 7.5 A
- Total power:
- 1600 W
- Power Factor Correction (PFC) type:
- Active
- Combined power (+3.3V):
- 150 W
- Combined power (+12V):
- 1600 W
- Combined power (+5V):
- 150 W
- Combined power (-12V):
- 9.6 W
- Combined power (+5Vsb):
- 17.5 W
- Max output current (+3.3V):
- 30 A
- Max output current (+12V):
- 133.3 A
- Max output current (+5V):
- 30 A
- Max output current (-12V):
- 0.8 A
- Max output current (+5Vsb):
- 3.5 A
- Hold time:
- 16 ms
- Efficiency:
- 92%
- Power Good signal delay range:
- 100 - 150 ms
- Power protection features:
- Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
- Width:
- 150 mm
- Depth:
- 190 mm
- Height:
- 86 mm
- Fan diameter:
- 12 cm
- Fan location:
- Top
- On/off switch:
- Yes
- Cooling type:
- Active
- Peripheral (Molex) power connectors (4-pin):
- 6
- Weight:
- 5.3 kg
- Cables included:
- null
- Package width:
- 410 mm
- Package depth:
- 219 mm
- Package height:
- 145 mm
- Package weight:
- 5.58 kg
- Power supply unit (PSU) form factor:
- ATX
- 80 PLUS certification:
- 80 PLUS Platinum
- ATX version:
- 3.1
- Bearing technology:
- DBB
- Mean time between failures (MTBF):
- 100000 h
- Motherboard power connector:
- 20+4 pin ATX
- Motherboard power cable length:
- 61 cm
- Number of SATA power connectors:
- 16
- PCI Express power connectors (6+2 pin):
- 8
- CPU power connector (4+4 pin):
- Yes
- ATX power connector (20+4 pin):
- Yes
- Floppy drive power connector:
- null
- Floppy disk drive connector:
- null
- PCI Express connector:
- Yes
- Cabling type:
- Fully-Modular
- SATA power cable length:
- 150,650 mm
- Peripheral (Molex) power cable length:
- null
- PCI Express power connectors (16-pin):
- null
- PCI Express power cable length:
- null
- CPU power cable length:
- null
- EPS power connector (4+4 pin):
- Yes
- Number of PATA power connectors:
- null
- AC input voltage:
- 100 - 240 V
- AC input frequency:
- 50/60 Hz
- Input current:
- 15 - 7.5 A
- Total power:
- 1600 W
- Power Factor Correction (PFC) type:
- Active
- Combined power (+3.3V):
- 150 W
- Combined power (+12V):
- 1600 W
- Combined power (+5V):
- 150 W
- Combined power (-12V):
- 9.6 W
- Combined power (+5Vsb):
- 17.5 W
- Max output current (+3.3V):
- 30 A
- Max output current (+12V):
- 133.3 A
- Max output current (+5V):
- 30 A
- Max output current (-12V):
- 0.8 A
- Max output current (+5Vsb):
- 3.5 A
- Hold time:
- 16 ms
- Efficiency:
- 92%
- Power Good signal delay range:
- 100 - 150 ms
- Power protection features:
- Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
- Maximum input current (@110V):
- null
- Maximum input current (@220V):
- null
- Width:
- 150 mm
- Depth:
- 190 mm
- Height:
- 86 mm
