Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge technology.
X3D Turbo Mode: Unleash new era gaming performance|DDR5 OC up to 8200MT/s, dual Channel DDR5|AMD Socket AM5: Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Processors|Digital twin 14+2+2 phases VRM solution|M.2 EZ-Flex: high-efficiency heat dissipation & flexible baseplate for M.2 SSD(Exclusive Patented Design)|WIFI EZ-Plug: Quick and easy design for Wi-Fi antenna installation|EZ-Latch Plus: PCIe and M.2 slots with Quick Release & Screwless Design|EZ-Latch Click: M.2 heatsinks with screwless design|Ultra-Fast Storage: 4*M.2 slots, including PCIe 5.0 x4|Efficient Thermal: VRM Thermal Armor Advanced & M.2 Thermal Guard L & M.2 Thermal Guard Ext|Fast Networking: 5GbE LAN & Wi-Fi 7 with directional Ultra-high gain antenna
- BIOS type:
- UEFI AMI
- BIOS memory size:
- 512 Mbit
- ACPI version:
- 5
- PCI Express x16 (Gen 4.x) slots:
- 1
- PCI Express x16 (Gen 5.x) slots:
- 1
- Number of M.2 (M) slots:
- 4
- Motherboard form factor:
- ATX
- Motherboard chipset:
- AMD B850
- Audio output channels:
- 7.1 channels
- Audio chip:
- Realtek ALC897
- Maximum resolution:
- 4096 x 2160 pixels
- USB 2.0 connectors:
- 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors:
- 1
- Number of SATA III connectors:
- 2
- USB 3.2 Gen 2x2 connectors:
- 1
- ATX Power connector (24-pin):
- Yes
- Number of CPU fan connectors:
- 2
- Number of chassis fan connectors:
- 6
- Number of EPS power connectors (8-pin):
- 1
- Number of water pump connectors:
- 3
- Number of temperature sensor headers:
- 2
- Number of noise detection headers:
- 1
- Number of RGB LED pin headers:
- 4
- TPM connector:
- Yes
- 12V power connector:
- Yes
- Peripheral (Molex) power connectors (4-pin):
- 1
- Supported memory types:
- DDR5-SDRAM
- Number of memory slots:
- 4
- Maximum internal memory:
- 256 GB
- Memory slots type:
- DIMM
- Memory channels:
- Dual-channel
- ECC сompatibility:
- Non-ECC
- Supported memory clock speeds:
- 8200,8000,7950,7900,7800,7600,7400,7200,7000,6800,6600,6400,6200,6000,5800,5600,5200,4800,4400 MHz
- Supported memory clock speed (max):
- 8200 MHz
- Unbuffered memory:
- Yes
- Maximum internal memory per slot:
- 64 GB
- Wi-Fi:
- Yes
- Ethernet interface type:
- 5 Gigabit Ethernet
- LAN controller:
- Realtek RTL8126
- Top Wi-Fi standard:
- Wi-Fi 7 (802.11be)
- Wi-Fi standards:
- 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
- WLAN controller model:
- Realtek RTL8922AE
- Bluetooth version:
- 5.4
- Weight:
- 3.63 kg
- Antenna included:
- Yes
- Screws included:
- Yes
- Bundled software:
- Norton® Internet Security (OEM version)
- Package width:
- 310 mm
- Package depth:
- 340 mm
- Package height:
- 92 mm
- Package weight:
- 4.14 kg
- Processor socket:
- Socket AM5
- Compatible processor series:
- AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
- USB 2.0 ports quantity:
- 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
- 4
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
- 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity:
- 1
- Ethernet LAN (RJ-45) ports:
- 1
- HDMI ports quantity:
- 1
- Headphone outputs:
- 1
- S/PDIF out port:
- Yes
- WiFi-AP antenna jack:
- 2
- HDMI version:
- 2.1
- Line-in:
- Yes
- Digital audio optical out:
- 1
- Supported storage drive interfaces:
- M.2, PCI Express 4.0, PCI Express 5.0, SATA III
- Supported storage drive types:
- HDD & SSD
- Number of HDDs supported:
- 2
- Number of storage drives supported:
- 6
- RAID levels:
- 0, 1, 5, 10
- Width:
- 305 mm
- Depth:
- 244 mm
- Height:
- 35 mm
- BIOS type:
- UEFI AMI
- BIOS memory size:
- 512 Mbit
- ACPI version:
- 5
- Clear CMOS button:
- null
- PCI Express x16 (Gen 4.x) slots:
- 1
- PCI Express x16 (Gen 5.x) slots:
- 1
- Number of M.2 (M) slots:
- 4
- PCI Express x16 slots:
- null
- PCI Express x1 (Gen 3.x) slots:
- null
- PCI Express x16 (Gen 3.x) slots:
- null
- PCI Express x1 (Gen 4.x) slots:
- null
- PCI Express x4 slots:
- null
- PCI Express x4 (Gen 4.x) slots:
- null
- PCI Express x8 (Gen 3.x) slots:
- null
- PCI Express x8 (Gen 4.x) slots:
- null
- PCI Express x8 (Gen 5.x) slots:
- null
- Motherboard form factor:
- ATX
- Motherboard chipset:
- AMD B850
- Audio output channels:
- 7.1 channels
- Audio chip:
- Realtek ALC897
- Maximum resolution:
- 4096 x 2160 pixels
- USB 2.0 connectors:
- 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors:
- 1
- Number of SATA III connectors:
- 2
- USB 3.2 Gen 2x2 connectors:
- 1
- ATX Power connector (24-pin):
- Yes
- Number of CPU fan connectors:
- 2
- Number of chassis fan connectors:
- 6
- Number of EPS power connectors (8-pin):
- 1
- Thunderbolt headers:
- null
- Number of water pump connectors:
- 3
- Number of temperature sensor headers:
- 2
- Number of noise detection headers:
- 1
- Number of RGB LED pin headers:
- 4
- USB 3.2 Gen 2 (3.1 Gen 2) connectors:
- null
- Total number of SATA connectors:
- null
- TPM connector:
- Yes
- 12V power connector:
- Yes
- S/PDIF out connector:
- null
- Number of SATA Express connectors:
- null
- Serial port headers:
- null
- Parallel connector:
- null
- Chassis intrusion connector:
- null
- Audio connector:
- null
- Peripheral (Molex) power connectors (4-pin):
- 1
- Supported memory types:
- DDR5-SDRAM
- Number of memory slots:
- 4
- Maximum internal memory:
- 256 GB
- Memory slots type:
- DIMM
- Memory channels:
- Dual-channel
- ECC сompatibility:
- Non-ECC
- Supported memory clock speeds:
- 8200,8000,7950,7900,7800,7600,7400,7200,7000,6800,6600,6400,6200,6000,5800,5600,5200,4800,4400 MHz
- Supported memory clock speed (max):
- 8200 MHz
- Unbuffered memory:
- Yes
- Maximum internal memory per slot:
- 64 GB
- Supported memory module capacities:
- null
- Wi-Fi:
- Yes
- Ethernet interface type:
- 5 Gigabit Ethernet
- LAN controller:
- Realtek RTL8126
- Top Wi-Fi standard:
- Wi-Fi 7 (802.11be)
- Wi-Fi standards:
- 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
- WLAN controller model:
- Realtek RTL8922AE
- Bluetooth version:
- 5.4
- Weight:
- 3.63 kg
- PCI Express x4 (Gen 3.x) slots:
- null
- Antenna included:
- Yes
- Screws included:
- Yes
- Bundled software:
- Norton® Internet Security (OEM version)
- Cables included:
- null
- Package width:
- 310 mm
- Package depth:
- 340 mm
- Package height:
- 92 mm
- Package weight:
- 4.14 kg
- Processor socket:
- Socket AM5
- Compatible processor series:
- AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
- Maximum internal memory supported by processor:
- null
- USB 2.0 ports quantity:
- 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
- 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity:
- null
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
- 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity:
- 1
- Ethernet LAN (RJ-45) ports:
- 1
- VGA (D-Sub) ports quantity:
- null
- HDMI ports quantity:
- 1
- Headphone outputs:
- 1
- Microphone in:
- null
- S/PDIF out port:
- Yes
- Thunderbolt ports quantity:
- null
- WiFi-AP antenna jack:
- 2
- DisplayPorts quantity:
- null
- DisplayPort version:
- null
- USB 3.2 Gen 2x2 Type-C ports quantity:
- null
- HDMI version:
- 2.1
- USB connector type:
- null
- USB4 Gen 2x2 ports quantity:
- null
- Line-in:
- Yes
- Digital audio optical out:
- 1
- PS/2 ports quantity:
- null
- USB4 Gen 3x2 ports quantity:
- null
- Supported storage drive interfaces:
- M.2, PCI Express 4.0, PCI Express 5.0, SATA III
- Supported storage drive types:
- HDD & SSD
- Number of HDDs supported:
- 2
- Number of storage drives supported:
- 6
- RAID levels:
- 0, 1, 5, 10
- Width:
- 305 mm
- Depth:
- 244 mm
- Height:
- 35 mm
