Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge
Twin 16+2+2 Phases Digital VRM with 110A Smart Power Stage|Dual Channel DDR5：4*DIMMs|PCIe Gen5 with PCIe UD Slot X & EZ-Latch Plus|M.2 Gen5 with EZ-Latch Plus|Full Covered MOSFET Heatsinks & x16 Backplates|Wi-Fi 7 with WIFI EZ-Plug & Directional Antenna|Dual 10GbE LAN, Q-Flash Plus
- BIOS type:
- UEFI AMI
- BIOS memory size:
- 256 Mbit
- ACPI version:
- 5
- Clear CMOS button:
- Yes
- PCI Express x16 (Gen 4.x) slots:
- 1
- Number of M.2 (M) slots:
- 3
- Motherboard form factor:
- ATX
- Motherboard chipset:
- AMD B850
- Audio output channels:
- 7.1 channels
- Audio chip:
- Realtek ALC1220
- Maximum resolution:
- 4096 x 2160 pixels
- USB 2.0 connectors:
- 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors:
- 1
- Number of SATA III connectors:
- 4
- USB 3.2 Gen 2x2 connectors:
- 1
- ATX Power connector (24-pin):
- Yes
- Number of CPU fan connectors:
- 2
- Number of chassis fan connectors:
- 1
- Number of EPS power connectors (8-pin):
- 1
- Number of water pump connectors:
- 1
- Number of RGB LED pin headers:
- 4
- TPM connector:
- Yes
- 12V power connector:
- Yes
- Serial port headers:
- 1
- Peripheral (Molex) power connectors (4-pin):
- 1
- Supported memory types:
- DDR5-SDRAM
- Number of memory slots:
- 4
- Maximum internal memory:
- 256 GB
- Memory slots type:
- DIMM
- Memory channels:
- Dual-channel
- ECC сompatibility:
- ECC & Non-ECC
- Supported memory clock speeds:
- 4400,4800,5200,5600,6000,6200,6400,6600,6800,7000,7200,7600,7800,8000,8600 MHz
- Supported memory clock speed (max):
- 8600 MHz
- Unbuffered memory:
- Yes
- Maximum internal memory per slot:
- 64 GB
- Wi-Fi:
- Yes
- Ethernet interface type:
- 10 Gigabit Ethernet
- Top Wi-Fi standard:
- Wi-Fi 7 (802.11be)
- Wi-Fi standards:
- 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
- WLAN controller model:
- Realtek RTL8922AE
- Bluetooth version:
- 5.4
- Weight:
- 2.69 kg
- Antenna included:
- Yes
- Screws included:
- Yes
- Bundled software:
- Norton Internet Security (OEM version)\nLAN bandwidth management software
- Package width:
- 335 mm
- Package depth:
- 270 mm
- Package height:
- 80 mm
- Package weight:
- 3 kg
- Processor socket:
- Socket AM5
- Compatible processor series:
- AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
- USB 2.0 ports quantity:
- 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
- 4
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
- 3
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity:
- 1
- Ethernet LAN (RJ-45) ports:
- 1
- HDMI ports quantity:
- 1
- Headphone outputs:
- 1
- Microphone in:
- Yes
- WiFi-AP antenna jack:
- 2
- DisplayPorts quantity:
- 1
- Supported storage drive interfaces:
- M.2, SATA III
- Supported storage drive types:
- HDD & SSD
- Number of HDDs supported:
- 4
- Number of storage drives supported:
- 7
- RAID levels:
- 0, 1, 10
- Width:
- 305 mm
- Depth:
- 244 mm
- Height:
- 35 mm
- BIOS type:
- UEFI AMI
- BIOS memory size:
- 256 Mbit
- ACPI version:
- 5
- Clear CMOS button:
- Yes
- PCI Express x16 (Gen 4.x) slots:
- 1
- PCI Express x16 (Gen 5.x) slots:
- null
- Number of M.2 (M) slots:
- 3
- PCI Express x16 slots:
- null
- PCI Express x1 (Gen 3.x) slots:
- null
- PCI Express x16 (Gen 3.x) slots:
- null
- PCI Express x1 (Gen 4.x) slots:
- null
- PCI Express x4 slots:
- null
- PCI Express x4 (Gen 4.x) slots:
- null
- PCI Express x8 (Gen 3.x) slots:
- null
- PCI Express x8 (Gen 4.x) slots:
- null
- PCI Express x8 (Gen 5.x) slots:
- null
- Motherboard form factor:
- ATX
- Motherboard chipset:
- AMD B850
- Audio output channels:
- 7.1 channels
- Audio chip:
- Realtek ALC1220
- Maximum resolution:
- 4096 x 2160 pixels
- USB 2.0 connectors:
- 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors:
- 1
- Number of SATA III connectors:
- 4
- USB 3.2 Gen 2x2 connectors:
- 1
- ATX Power connector (24-pin):
- Yes
- Number of CPU fan connectors:
- 2
- Number of chassis fan connectors:
- 1
- Number of EPS power connectors (8-pin):
- 1
- Thunderbolt headers:
- null
- Number of water pump connectors:
- 1
- Number of temperature sensor headers:
- null
- Number of noise detection headers:
- null
- Number of RGB LED pin headers:
- 4
- USB 3.2 Gen 2 (3.1 Gen 2) connectors:
- null
- Total number of SATA connectors:
- null
- TPM connector:
- Yes
- 12V power connector:
- Yes
- S/PDIF out connector:
- null
- Number of SATA Express connectors:
- null
- Serial port headers:
- 1
- Parallel connector:
- null
- Chassis intrusion connector:
- null
- Audio connector:
- null
- Peripheral (Molex) power connectors (4-pin):
- 1
- Supported memory types:
- DDR5-SDRAM
- Number of memory slots:
- 4
- Maximum internal memory:
- 256 GB
- Memory slots type:
- DIMM
- Memory channels:
- Dual-channel
- ECC сompatibility:
- ECC & Non-ECC
- Supported memory clock speeds:
- 4400,4800,5200,5600,6000,6200,6400,6600,6800,7000,7200,7600,7800,8000,8600 MHz
- Supported memory clock speed (max):
- 8600 MHz
- Unbuffered memory:
- Yes
- Maximum internal memory per slot:
- 64 GB
- Supported memory module capacities:
- null
- Wi-Fi:
- Yes
- Ethernet interface type:
- 10 Gigabit Ethernet
- LAN controller:
- null
- Top Wi-Fi standard:
- Wi-Fi 7 (802.11be)
- Wi-Fi standards:
- 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
- WLAN controller model:
- Realtek RTL8922AE
- Bluetooth version:
- 5.4
- Weight:
- 2.69 kg
- PCI Express x4 (Gen 3.x) slots:
- null
- Antenna included:
- Yes
- Screws included:
- Yes
- Bundled software:
- Norton Internet Security (OEM version)\nLAN bandwidth management software
- Cables included:
- null
- Package width:
- 335 mm
- Package depth:
- 270 mm
- Package height:
- 80 mm
- Package weight:
- 3 kg
- Processor socket:
- Socket AM5
- Compatible processor series:
- AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
- Maximum internal memory supported by processor:
- null
- USB 2.0 ports quantity:
- 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
- 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity:
- null
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
- 3
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity:
- 1
- Ethernet LAN (RJ-45) ports:
- 1
- VGA (D-Sub) ports quantity:
- null
- HDMI ports quantity:
- 1
- Headphone outputs:
- 1
- Microphone in:
- Yes
- S/PDIF out port:
- null
- Thunderbolt ports quantity:
- null
- WiFi-AP antenna jack:
- 2
- DisplayPorts quantity:
- 1
- DisplayPort version:
- null
- USB 3.2 Gen 2x2 Type-C ports quantity:
- null
- HDMI version:
- null
- USB connector type:
- null
- USB4 Gen 2x2 ports quantity:
- null
- Line-in:
- null
- Digital audio optical out:
- null
- PS/2 ports quantity:
- null
- USB4 Gen 3x2 ports quantity:
- null
- Supported storage drive interfaces:
- M.2, SATA III
- Supported storage drive types:
- HDD & SSD
- Number of HDDs supported:
- 4
- Number of storage drives supported:
- 7
- RAID levels:
- 0, 1, 10
- Width:
- 305 mm
- Depth:
- 244 mm
- Height:
- 35 mm
