Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge
Supports Intel Core 14th/ 13th /12th processors|Unparalleled Performance: Hybrid 4+1+1 Phases Digital VRM Solution|Dual Channel DDR4: 4*DIMMs XMP Memory Module Support|Next Generation Storage: 2*PCIe 4.0 x4 M.2 Connectors|Fast Networks: Wi-Fi 6 802.11ax, GbE LAN|Extended Connectivity: Front USB-C 5Gb/s, DP, HDMI|Smart Fan 6: Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP|Q-Flash Plus: Update BIOS Without Installing the CPU, Memory and Graphics Card
- BIOS type:
- UEFI AMI
- BIOS memory size:
- 128 Mbit
- ACPI version:
- 5
- PCI Express x16 (Gen 4.x) slots:
- 1
- Number of M.2 (M) slots:
- 2
- PCI Express x1 (Gen 3.x) slots:
- 2
- Motherboard form factor:
- micro ATX
- Motherboard chipset:
- Intel B760
- Audio output channels:
- 7.1 channels
- Audio chip:
- Realtek ALC897
- Maximum resolution:
- 4096 x 2304 pixels
- USB 2.0 connectors:
- 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors:
- 2
- Number of SATA III connectors:
- 4
- ATX Power connector (24-pin):
- Yes
- Number of CPU fan connectors:
- 1
- Number of chassis fan connectors:
- 3
- Number of EPS power connectors (8-pin):
- 1
- Number of RGB LED pin headers:
- 2
- TPM connector:
- Yes
- S/PDIF out connector:
- Yes
- Serial port headers:
- 1
- Parallel connector:
- Yes
- Supported memory types:
- DDR4-SDRAM
- Number of memory slots:
- 4
- Maximum internal memory:
- 128 GB
- Memory slots type:
- DIMM
- Memory channels:
- Dual-channel
- ECC сompatibility:
- ECC & Non-ECC
- Supported memory clock speeds:
- 4000,4133,4266,4300,4400,4500,4600,4700,4800,4933,5000,5133,5333 MHz
- Supported memory clock speed (max):
- 5333 MHz
- Unbuffered memory:
- Yes
- Maximum internal memory per slot:
- 32 GB
- Wi-Fi:
- Yes
- Ethernet interface type:
- Gigabit Ethernet
- LAN controller:
- Realtek RTL8111H
- Top Wi-Fi standard:
- Wi-Fi 6 (802.11ax)
- Wi-Fi standards:
- 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
- WLAN controller model:
- Realtek RTL8851BE
- Bluetooth version:
- 5.3
- Weight:
- 1.1 kg
- Antenna included:
- Yes
- Bundled software:
- Norton® Internet Security (OEM version)\nLAN bandwidth management software
- Processor socket:
- LGA 1700
- Compatible processor series:
- Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel Core i5 13th Gen, Intel Core i5 14th Gen, Intel Core i7 13th Gen, Intel Core i7 14th Gen, Intel Core i9 12th Gen, Intel Core i9 13th Gen, Intel Core i9 14th Gen
- Maximum internal memory supported by processor:
- 128 GB
- USB 2.0 ports quantity:
- 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
- 3
- Ethernet LAN (RJ-45) ports:
- 1
- HDMI ports quantity:
- 1
- Headphone outputs:
- 1
- WiFi-AP antenna jack:
- 2
- DisplayPorts quantity:
- 1
- DisplayPort version:
- 1.2
- Line-in:
- Yes
- PS/2 ports quantity:
- 1
- Supported storage drive interfaces:
- M.2, SATA III
- Supported storage drive types:
- HDD & SSD
- Number of HDDs supported:
- 4
- Number of storage drives supported:
- 6
- RAID levels:
- 0, 1, 5, 10
- Width:
- 244 mm
- Depth:
- 244 mm
- Height:
- 35 mm
